KETELES K800 Dual-Motor Ebike: Answers to Common Questions

Hi Everyone, Congratulations on becoming the proud owner of theKETELES K800 dual-motor ebike! This powerful machine offers a thrilling blend of speed, efficiency, and versatility. However, as with any advanced tech, new users often have questions about settings, motor functionality, and performance. Below, we’ll address three common queries to help you maximize your riding experience.

1. Standard P Settings for the KETELES K800

The "P settings" (short for Parameter Settings) on your K800 let you adjust motor performance, throttle sensitivity, and other vital functions. Though exact settings might differ slightly due to firmware updates, here's a simplified guide to standard configurations:

Personalized parameter settings

Each setting needs to be done with the bicycle stationary.The personalized parameter setting procedure is as follows:

When the display is ON and the speed shows 0,

(1) Press and hold  simultaneously for more than 2 seconds to enter the personalized parameter setting interface.

 (2) Press /to toggle between the personalized parameter setting interface, and press  to enter the parameter changing state.

 (3) Press /to select the parameter, long pres for addition operation, long press for subtraction operation.

 (4) Press to save the parameter settings and return to the personalized parameter setting interface.

(5) Long Press to save the parameter settings and exit the personalized parameter setting interface.

 The following options are available on the personalized parameter setting interface:

• Backlight luminance setting

01P is the backlight luminance setting. Parameters 01, 02 and 03 are available, which represent the backlight luminance, 01 for the minimum luminance, 02 for the standard luminance and 03 for the maximum luminance.

Press the button to enter the parameter modification interface. Press the button  / for parameter selection. Press the button  to save the parameter and return to the selection interface of general setting options.

 • Metric and Imperial setting

02P is the metric and imperial setting, 00 for metric and 01 for imperial. Press to enter the parameter changing state. Press the / to select the parameter and press to save the parameter setting and return to the personalized parameter setting interface

• Rated voltage setting

03P is the rated voltage setting. The available rated voltage range is: 24V, 36V, 48V. Press to enter the parameter changing state. Press the / to select the parameter and press to save the parameter setting and return to the personalized parameter setting interface..

• Auto Sleep Time Setting

04P is the auto sleep time setting.

To save the battery power and reach higher range, this display will be turned off after it has not been used for a time. The adjustable range is: 1~60min, 00 means no auto shutdown. The factory default setting is 10 minutes.

Press to enter the parameter changing state. Press the / to select the parameter and press to save the parameter setting and return to the personalized parameter setting interface.

 • PAS level setting

05P is the Pedal assist level setting.

The available PAS level settings are: 0~3, 1~3, 0~5, 1~5, 1~7, 0~7, 0~9, 1~9.

Press to enter the parameter changing state. Press the / to select the parameter and press  to save the parameter setting and return to the personalized parameter setting interface

 Pro Tip: To access P settings, power on the bike while holding the“+”and“-”buttons on the display. Use the arrow keys to navigate. Always save changes before exiting.

 Note: Refer to your user manual for model-specific details, as some settings may differ.

2. Does the Front Motor Only Work on the Throttle?

No—the front motor on the KETELES K800 only works when using the throttle. It does not engage in pure pedal-assist (PAS) mode.

The KETELES K800 electric bicycle employs adual-motor powertrain configurationwith distinct operational protocols for each drive unit.

• Throttle Mode: Twisting the throttle activates both motorsat once, delivering maximum power. This is perfect for rapid acceleration or tackling steep hills.

 3. Does the Front Motor Only Kick In After a Certain Speed?

The K800 dual-motor e-bike does not have this feature.

The K800 front motor is used by switching the front motor on and off when not in use.

Throttle mode: Both motors start immediately regardless of speed.

Importance:

The KETELES K800’s dual-motor system is highly flexible, but fine-tuning it requires some experimentation. By adjusting the P settings (Parameter Settings) and learning how the motors activate, you can maximize the bike’s performance.

• Safety first: Always wear a helmet and check local laws and regulations regarding e-bike speed limits.

 Conclusion

The KETELES K800’s dual-motor system offers incredible flexibility, but mastering its settings takes a bit of trial and error. By customizing your P parameters and understanding motor engagement, you’ll unlock the bike’s full potential.

If you have any questions about the use or function of the product, please leave a detailed message in the comment area - our professional team will provide you with one-on-one answer support.

Please be sure to obey traffic rules during riding, wear safety gear, maintain a reasonable speed, and ensure that every trip is safe and smooth.

I wish you to fully experience the fun of electric riding in your exploration journey and have an unforgettable experience!🚴♂️💨
